Shuttle Star BGA Rework Station Machines
Next Node Innovations distributes Shuttle Star BGA rework station machines for electronics technicians, engineers and repair operations. With more than 30 years of experience, we provide Shuttle Star BGA rework systems supported by free training, lifetime technical support and a one-year parts warranty.
Request a Quote
The Value of Shuttle Star BGA Rework Technology
Shuttle Star manufactures BGA rework systems for component removal, replacement and installation across PCB assemblies. These systems deliver split-vision optical alignment, programmable thermal controls and automated component handling capabilities. Shuttle Star technology is widely used by professionals responsible for industrial electronics repairs, contract manufacturing and product development.
Purchasing Shuttle Star equipment from Next Node Innovations means getting the equipment you need, along with a complete support network. Trust us for ongoing technical assistance to help keep your operations moving on schedule.
Our Featured Shuttle Star Models
You can rely on Next Node Innovations for the following Shuttle Star BGA rework stations, each designed to meet diverse operational requirements and board dimensions.
Shuttle Star E6250U BGA Rework Station
This nitrogen-capable system handles boards up to 36 inches with movable X-Y top and bottom gas heaters. Other key capabilities of the E6250U include:
- Split-vision alignment: High-resolution optical system for PCB positioning.
- Flexible processing area: Movable heating heads to access parts at board edges.
- Automated handling: Built-in automatic soldering and mounting functions.
The Shuttle Star E6250U accommodates large server boards, network assemblies and complex PCBs demanding precise rework.
Shuttle Star SV560A BGA Rework Station
The automated system features high-definition imaging with auto X-Y and split-vision alignment for high-volume production. With the SV560A, professionals benefit from:
- Six-zone heating: 3,600-watt rapid IR underheater with 1,200-watt top heater and 800-watt bottom heater.
- High-definition optics: A two-million-pixel camera system with auto focus capabilities.
- Large board capacity: Accommodates boards up to 24 inches, with optional 36-inch compatibility upgrade.
Shuttle Star SV560 BGA Rework Station
The SV560 combines a split-vision optical system with 3,600 watts of heating power. This system also offers:
- Component support: Removes and places BGAs, CGAs, CSPs, QFPs, LGAs and SMDs.
- Advanced optics: Auto-focus split-vision camera with zoom and micro-adjustment functionality.
- Efficient thermal performance: Six-zone IR underheater with 1,200-watt top heater and 800-watt bottom heater.
- Self-contained operation: No external air source necessary due to PLC control.
Why Choose Next Node Innovations as Your Shuttle Star Distributor?
Next Node Innovations brings three decades of BGA rework expertise to the equipment distribution process. Our support framework includes thermal profile development tailored to the board assemblies you oversee, and we help establish documented procedures in accordance with IPC standards.
With lifetime technical support, you can reach our specialists whenever you have questions. Additionally, we provide BGA rework station training developed in compliance with IPC 7095 guidelines to help your operators learn proper equipment setup and thermal profiling techniques. Outside of equipment sales, we support you with BGA rework services for component installation, removal and reballing.
If you need BGA rework consulting, our team can help guide your operation based on real-world project experience.
Contact Next Node Innovations for Sales and Questions
Whether you need a nitrogen-capable system for lead-free assembly or an automated station for production, we help you select the Shuttle Star BGA rework station that aligns with your goals and current facility layout.
Contact Next Node Innovations to discuss your BGA rework needs today.
